IPAQ C201 (Discontinued)

Analog PC-Programmable 2-wire Transmitter for Pt100 Input

IPAQ C201 is an analog, non-isolated, easy-to-use 2-wire transmitter for Pt100 input. Configuration is made in seconds with the user friendly software, ConSoft. No external power supply required for configuration.
IPAQ C201 is designed for Pt100 in 3-wire connection according to
different standards.

  • Robust terminals with test connections
  • Only 18.5 mm / 0.72 inch high
  • Input: Pt100 in 3-wire connection
  • PC configurable measuring ranges without need for calibration
  • Temperature linear output
  • Very short response time
  • Excellent EMC immunity
  • Configuration without external power
  • Easy-to-use Windows configuration software
  • USB communication
  • Withstands vibrations up to 10 g

IPAQ C201 is being phased out and will be replaced by IPAQ C202.

Category: .

Technical Specification

TypeHead-mounted
InputRTD
Input RTDPt100
Type Of TransmitterAnalog
Output4-20 mA
IsolationUnisolated
Measuring channels1 channel
Input connections3-wire connection
Power supply8.5 to 32 VDC
Typical accuracyMax. of ±0.1 °C / ±0.2 °F or ±0,1 % of span
Quick deliveryYes
